Vinyl Laminate
Gypsum Ceiling Tiles
Arish™ Gypsum Ceiling Tiles are manufactured with an incombustible gypsum core, lined with paper bonded on both sides. It comes in Superior Quality Vinyl Laminates, available in embossed, plain & printed patterns which are recognized in providing aesthetic appearance along with the long lasting and low maintenance. The vinyl surface requires no further decoration; it is easily cleaned and provides good light reflection
ProTiles can be supplied in: Front Vinyl with Paper Backing, Front Vinyl Laminated with polished Aluminum Foil Backing.
The vinyl foil are classified as Class "2" in the Flame Spread Test in accordance to British Standard 476 Part 7: 1971
Foiled Backed Ceiling Tiles:
ProTile™ with Foil Backing is bonded with the special aluminum foil sheet at the back liner, which prevents heat penetration, provides effective vapor retardant and provides good reflective thermal insulation values respectively. It is ideal for use in top floors of the commercial and residential buildings that are directly affected by heat or sunlight.
Thermal Analysis: ASTM C – 168 (Heat Transfer Coefficient: 0.22 W/m K)
|
|
Key Benefits:
- The vinyl panel’s seals out bacteria, dirt and odors.
- Prevents heat penetration
- Hard washable surfaces
- Non-combustible, fire resistance
- Provides good light reflection.
Gypsum Ceiling Tile Construction
Grid Ceiling System:
Grid Ceiling system promotes complete design flexibility and installed in exposed T-Bar metal system or similar lay-in-modular grid suspended ceiling system.
Grid system ensures the precise and easy installation of ceiling tiles. The Grid system is mobile, thus can be moved to another location if required.
Applications:
Ideal for use in executive offices, lobbies, hospitals, hotels, conference rooms, computer labs and restaurants.
Installation of Grid Ceiling:
This system is easy to install, it gives better access for both working and maintenance area. The complete system consists of T-Bar metal system.
Steps:
- Determine the required ceiling level, mark the position and fix the wall Angle on the wall. Screws, stub nails or dry fasteners should be used for installation onto wall angles, depending on type of wall.
- The main Tee should be suspended from the overhead structure with gauge 14 galvanized steel wires together with a hanger bracket; the spacing for the main Tee should be 48” or 24” from center to center
- Cross Tee should be inserted into the Main Tee slot and locked into position using slight forward pressure.
- Adjust all levels and alignments of the whole grid system precisely,
- Install Arish square-cut Gypsum Tile as required.
Quality Assurance
Our products are manufactured on International Quality Management System of ISO 9001-2008.
